5kg low-power pan tilt platform,suitable ptz cameras-radars pan tilt and robot tilt vs pan,etc.


Collection：0
Net weight：≈4kg
Max load：≤3~5kg
Delivery cycle：4~8 W/D
Order series：JSA-EFPTZDU20  Series
Detail




█ Specifications


Model

JSA-EFPTZDU20 Series

Max. Load

≤5Kg

Bearing mode

Top load/(side load compatible)

Driving mode

Gear drive

Pan Angle

0°～360°

Tilt Angle

-60°~60°   Optional

Pan Speed

0.1°～18°/S

Tilt Speed

0.1°～10°/S

Preset Accuracy

±0.1°

Preset

≤200

Auto cruise

Support

Interfaced
RS485

Protocol

Pelco_D

Baud Rate

9600

Address

1

Bottom cable

DC9～36V*1、RS485*1、RJ45*1、GND*1；Optional other lines can be customized on demand

Top cable

DC24V*1、DC12V*1、RS485*1、RJ45*1、GND*1；Optional other lines can be customized on demand

Angle return

Optional Angle and orientation data query return

Input voltage range

DC9～36V 50/60HZ；≤15W

Operating temperature

-40℃~+70℃

Working humidity

<90%RH

Lightning protection

Input voltage range supply ≤4000V, communication and video signal ≤2000V

Protection level

Standard configurationIP66; Optional Anti-salt spray treatment

Weight

≈4kg

Size

154×270mm


█ Size

pan tilt head

█ Order model



Model
Load
   /Kg
Angle range
Speed range
Preset Accuracy
Angle feedback
Top outlet
Bottom cable entry
Pan
Tilt
Pan
Tilt
JSA-EFPTZDU205
5
0°~360°
-60°~60°
0.1°～18°/S
0.1°～10°/S
±0..1°

                Optional
RS485*1
DC24V*1
DC12V*1
GND*1
RJ45*1[100Mb]
 		RS485*1
DC9~36V*1
GND*1
RJ45*1[100Mb]
Project customization
Based on this standard model, we can customize the Pan or Tilt angle range, bottom input cable, top output cable, software, etc. according to the customer's individual needs.



█ Package weight
