5~7kg light load pan and tilt head,suitable ptz cameras-radars pan tilt and robot tilt vs pan,etc.


Collection：0
Net weight：≈4.8kg
Max load：≤5~7kg
Delivery cycle：4~8 W/D
Order series：JSA-EFPTZDU30L  Series
Detail





█ Specifications


Model

JSA-EFPTZDU30L07 / JSA-EFPTZDU30LH07

JSA-EFPTZDU30L05 / JSA-EFPTZDU30LH05

Max   Load

≤7Kg

≤5Kg

Bearing mode

Top load/(side load compatible)

Driving mode

Gear drive

Pan Angle

0°～360°

Tilt Angle

-85°～+20°

-85°～+60°

Pan Speed

1°～9°/S，Optional 0.1°～9°/S

Tilt Speed

1°～5°/S，Optional 0.1°～5°/S

Preset Accuracy

± 1° / optional ± 0.1°

Preset

≤80

Auto cruise

Support

Interfaced
RS485

Protocol

Pelco_D

Baud Rate

9600

Address

1

Bottom cable

AC24V*1、RS485*1、RJ45*1、GND*1

DC10~18V*1、RS485*1、RJ45*1、GND*1

Top cable

AC24V*1、DC12V*1、RS485*1、RJ45*1、GND*1

DC12V*2、RS485*1、RJ45*1、GND*1

Angle return

Not support

Input voltage range

AC24V 50/60HZ；≤80W

DC10~18V 50/60HZ；≤20W

Operating temperature

-30℃~+60℃

Working humidity

<90%RH

Lightning protection

Input voltage range supply ≤4000V, communication and video signal ≤2000V

Prevention grade

IP66

Weight

≈4.8kg

Size

183mm(L)×167mm(W)×285mm(H)


█ Size

tilt vs pan

█ Order model


Model
Load
   /Kg
Angle range
Speed range
Preset Accuracy
Angle feedback
Top outlet
Bottom cable entry
Pan
Tilt
Pan
Tilt
JSA-EFPTZDU30L05
5
0°~360°
-85°~60°
1°～9°/S
1°～5°/S
±.1°
Optional
GND*1
RS485*1
DC12V*2
RJ45*1[100Mb]
GND*1
RS485*1
DC10~18V*1
RJ45*1[100Mb]
JSA-EFPTZDU30LH05
0.1°～9°/S
0.1°～5°/S
±.0.1°
JSA-EFPTZDU30L07
7
-85°~20°
1°～9°/S
1°～5°/S
±.1°
GND*1
   RS485*1
   AC24V*1
   DC12V*1
   RJ45*1[100Mb]		GND*1
   RS485*1
   AC24V*1
   RJ45*1[100Mb]
JSA-EFPTZDU30LH07
0.1°～9°/S
0.1°～5°/S
±.0.1°
Project customization
Based on this standard model, we can customize the Pan or Tilt angle range, bottom input cable, top output cable, software, etc. according to the customer's individual needs.
